With the integrated flip chips, adjustable headset and an aftermarket 29” rear wheel, Alpine Trail aluminum riders can select 12 unique configurations to run their bikes.
The all-new Alpine Trail aluminum models now feature our Bear Box integrated downtube storage, complete with a custom nylon bag with a weather-sealed zipper.
Chainstay and seatstays are protected with durable rubber guards that minimize noise and protect paint finishes, and integrated downtube guards helps deflect errant rocks.
Using our proprietary headset cups and inserts, the headtube angle on Alpine Trail aluminum models can be adjusted giving the rider three options.
The Alpine Trail series is our boldest and most capable line of enduro bikes ever, built upon our most advanced, most adjustable frames to date.
Series 4 aluminum MultiTrac 2 LT frames feature mixed 29”/27.5” wheels, 170mm front and 160mm rear travel, and the utmost in adjustability. Riders can alter the head tube angle and bottom bracket/chainstay length, as well as run 29” rear wheels if desired. “Bear Box” downtube storage includes a zippered nylon bag to house trail essentials, and a 34.9mm seatpost increases strength and is compatible with the latest dropper posts.
"XR" = "Xtra Rad" here at Marin, and like the XR models that have preceded the new Alpine Trail, we created a model for the more discriminating rider. We focused our efforts on building a bike with high performance RockShox Ultimate-level suspension, a SRAM GX Eagle Lunar 12-speed drivetrain and DB8 4-piston brakes - all equipment that helps the rider level up, but without blowing the budget. Don't forget the Maxxis rubber and our proprietary CNC machined 35mm stem and matching Trail Bar.
| frame | All New Series 4 6061 Aluminum |
| front suspension | RockShox Zeb Ultimate, 170mm Travel, 29", 110x15mm Maxle Stealth, 44mm Offset |
| rear suspension | RockShox Super Deluxe Coil Ultimate, 205x65, 30xM8 Lower Hardware, Custom Tune, Spring Rates S/M- 350lbs, L/XL-450lbs |
| rim | Marin, Double Wall Alloy, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible |
| hub rear | Formula, DCL-3482, 148x12, 4 Sealed Bearings, 6-Bolt Disc, XD Driver, 32H |
| hub front | Formula, DC-711, 110x15mm, 6-Bolt Disc, 32h |
| spokes | 14g Black Stainless Steel |
| tires | Maxxis Assegai MAXX GRIP, Front 29x2.5 EXO+, Rear 27.5x2.5" DoubleDown, Tubeless compatible |
| derailleur rear | SRAM GX Eagle Lunar 12-Speed |
| shift lever | SRAM GX Eagle Lunar MMX Mount |
| crankset | SRAM GX Eagle, 32T, 55MM CL, 170MM Length |
| bottom bracket | SRAM DUB MTB 73 |
| chain | SRAM NX Eagle |
| cassette | SRAM GX 1275 T-Type 10-52T |
| brakes front | SRAM DB8 4-Piston Hydraulic Disc, HSC 200mm Rotor |
| brakes rear | SRAM DB8 4-Piston Hydraulic Disc, HSC 200mm Rotor |
| brake levers | SRAM DB8 Hydraulic |
| handlebar | Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back |
| stem | Marin CNC, 35mm Length, 35mm Bar Bore |
| grips | Marin Grizzly Lock-On |
| headset | FSA Custom, Adjustable HTA Design |
| seatpost | TranzX, YSP39 1x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm |
| saddle | Marin Speed Concept |
| extras | Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Groupset Model | GX Eagle |
| Fork Brand | Rockshox |
| Fork Travel | 141 - 170mm |
| Shock Travel | 141 - 170mm |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Enduro |
| FRAME | All New Series 4 6061 Aluminum |
| FRONT SUSPENSION | RockShox Zeb Ultimate, 170mm Travel, 29", 110x15mm Maxle Stealth, 44mm Offset |
| REAR SUSPENSION | RockShox Super Deluxe Coil Ultimate, 205x65, 30xM8 Lower Hardware, Custom Tune, Spring Rates S/M- 350lbs, L/XL-450lbs |
| Rim | Marin, Double Wall Alloy, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible |
| Hub Rear | Formula, DCL-3482, 148x12, 4 Sealed Bearings, 6-Bolt Disc, XD Driver, 32H |
| Hub Front | Formula, DC-711, 110x15mm, 6-Bolt Disc, 32h |
| SPOKES | 14g Black Stainless Steel |
| Tires | Maxxis Assegai MAXX GRIP, Front 29x2.5 EXO+, Rear 27.5x2.5" DoubleDown, Tubeless compatible |
| DERAILLEUR REAR | SRAM GX Eagle Lunar 12-Speed |
| Shift Lever | SRAM GX Eagle Lunar MMX Mount |
| Crankset | SRAM GX Eagle, 32T, 55MM CL, 170MM Length |
| Bottom Bracket | SRAM DUB MTB 73 |
| Chain | SRAM NX Eagle |
| Cassette | SRAM GX 1275 T-Type 10-52T |
| Brakes Front | SRAM DB8 4-Piston Hydraulic Disc, HSC 200mm Rotor |
| Brakes Rear | SRAM DB8 4-Piston Hydraulic Disc, HSC 200mm Rotor |
| Brake Levers | SRAM DB8 Hydraulic |
| Handlebar | Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back |
| Stem | Marin CNC, 35mm Length, 35mm Bar Bore |
| GRIPS | Marin Grizzly Lock-On |
| Headset | FSA Custom, Adjustable HTA Design |
| Seatpost | TranzX, YSP39 1x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm |
| Saddle | Marin Speed Concept |
| EXTRAS | Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head |
| Adjustable Geometry | With the integrated flip chips, adjustable headset and an aftermarket 29” rear wheel, Alpine Trail aluminum riders can select 12 unique configurations to run their bikes. |
| Bear Box Downtube Storage | The all-new Alpine Trail aluminum models now feature our Bear Box integrated downtube storage, complete with a custom nylon bag with a weather-sealed zipper. |
| Protection | Chainstay and seatstays are protected with durable rubber guards that minimize noise and protect paint finishes, and integrated downtube guards helps deflect errant rocks. |
| Adjustable Headtube Angle | Using our proprietary headset cups and inserts, the headtube angle on Alpine Trail aluminum models can be adjusted giving the rider three options. |
