The eONE-EIGHTY 700 offers a perfect pairing of performance and price, thanks to a spec that's functional without being flash. Our tough aluminium frame serves up 180 mm of big-mountain-ready travel in an agile mixed wheel size package, while the powerful Bosch CX drive unit with 800 Wh battery means you can rip bike park laps all day long. RockShox's Zeb Select 180 mm fork and Vivid Select shock will tame anything the trail throws at you, and SRAM's GX Eagle drivetrain offers no-fuss shifting.
Calling all heavy hitters, bike park senders and big mountain brawlers, this one’s for you. The new eONE-EIGHTY has landed, and it’s ready to ride the biggest lines and burliest tracks - and you can say goodbye to waiting in the uplift queue because it can rip and repeat all day long thanks to a big 800 Wh battery and Bosch CX power.It’s our longest travel e-bike ever, with 180 mm of suspension at either end on a robust aluminium frame with a new suspension platform that builds on our award-winning FAST kinematic from the eONE-SIXTY and sends it to new heights. Add in coil shock compatibility, mixed-wheel size only setup, plus a whole host of other features and getting rowdy is where the eONE-EIGHTY starts, not finishes. Up or down, it’s ready to rock.It’s also our first e-MTB to use the Bosch Performance Line CX drive unit, which offers powerful assistance and silent performance with 85 Nm on tap. There’s a serious amount of range on offer too, thanks to the new 800 or 600 Wh battery - plus the option of a 250 Wh range extender. You can easily remove the battery for off-bike charging or replacement on a really big ride, plus we’ve also got a new cover that protects from dirt, impacts and moisture - and it holds itself in place with the magic of Fidlock magnets.It’s rated for Category 5 riding too, so you can get stuck into as many bike park laps or downhill tracks as you like without voiding the 5-year warranty.
Features:
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | eONE-EIGHTY LITE - material - aluminium - 180mm suspension travel - 27.5" x 2.5" max. wheelsize - 148x12mm axle standard |
| frame size | Short - Mid - Long - XLong |
| color | HERITAGE RED (BROWN) |
| fork | Rock Shox Zeb Select eMTB - Air - 180mm suspension travel - Tapered - 44mm fork offset - 29x2.6" max. wheelsize |
| shock | Rock Shox Vivid Select - platform |
| brake front | Sram DB8 Stealth - 4 piston |
| brake rear | Sram DB8 Stealth - 4 piston |
| rotor front | Sram HS2 - 220mm |
| rotor rear | Sram HS2 - 220mm |
| headset | Acros ICR MERIDA EXTERNAL - neck w/ Blocklock |
| handlebar | MERIDA EXPERT eTR - 780mm width - XS,S 20RHB - M,L,XL 30RHB |
| handlebar stem | MERIDA EXPERT eTR II - material - aluminium - 35mm diameter - 0° stem angle - Supernova mount - 40 mm all sizes |
| grip | MERIDA EXPERT EC |
| derailleur (r) | Sram GX Eagle |
| shifter front | Limotech RM10 (For SRAM MMX) |
| shifter rear | Sram GX Eagle Single Click |
| seat post | MERIDA TEAM TR II - 34.9mm diameter - 0mm setback - SHORT,MID and XLONG 30.9 - 230mm travel seatpost - XSHORT 30.9 - 200mm travel seatpost |
| seat clamp | MERIDA EXPERT |
| saddle | MERIDA COMP SL - 28% recycled material |
| pedal | VP VP-532 |
| chain | Sram TX Eagle |
| chainwheel | Sram Eagle Transmission E-MTB chainring - 36 teeth |
| crank | Sram GX Eagle E-MTB Crank - 165mm all sizes |
| freewheel | Sram CS PG1230 EAGLE 11-50T |
| rim | MERIDA EXPERT TR II - 110x15mm width front hub - 148x12mm width rear hub - 28mm inner width - material - aluminium - Tubeless ready (tubeless tape and valves not included) - for 29" |
| tyre front | Maxxis Assegai - 29x2.5" - fold - 3C TR MaxxGrip |
| tyre rear | Maxxis Minion DHR II - 27.5x2.4" - fold - 3C TR MaxxTerra |
| hub front | Shimano TC500 - 15x100mm width front hub - 32 spoke holes - Centerlock |
| hub rear | Shimano TC500 - 12x148mm width rear hub - 32 spoke holes - Centerlock |
| axle rear | MERIDA EXPERT TR - including removable lever - 6/4mm allen key |
| spokes | black stainless |
| light front | Lezyne Hecto StVZO E350+ Reverse - reverse MERIDA Custom Mount |
| light rear | USR REAR Light CG-24RG |
| battery lock | Abus Key |
| drive unit | Bosch Performance Line CX |
| battery | Bosch PowerTube 800 Wh - removable |
| display | Bosch Purion 400 |
| approx. weight | 27.0 kg - weighed at frame size M - Weight may vary depending on bike size - finish or possible specification changes due to supply chain issues. |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Groupset Model | NX Eagle |
| Fork Brand | Rockshox |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Enduro |
| FRAME | eONE-EIGHTY LITE - material - aluminium - 180mm suspension travel - 27.5" x 2.5" max. wheelsize - 148x12mm axle standard |
| Frame Size | Short - Mid - Long - XLong |
| COLOR | HERITAGE RED (BROWN) |
| Fork | Rock Shox Zeb Select eMTB - Air - 180mm suspension travel - Tapered - 44mm fork offset - 29x2.6" max. wheelsize |
| Shock | Rock Shox Vivid Select - platform |
| Brake Front | Sram DB8 Stealth - 4 piston |
| Brake Rear | Sram DB8 Stealth - 4 piston |
| ROTOR FRONT | Sram HS2 - 220mm |
| ROTOR REAR | Sram HS2 - 220mm |
| Headset | Acros ICR MERIDA EXTERNAL - neck w/ Blocklock |
| Handlebar | MERIDA EXPERT eTR - 780mm width - XS,S 20RHB - M,L,XL 30RHB |
| HANDLEBAR STEM | MERIDA EXPERT eTR II - material - aluminium - 35mm diameter - 0° stem angle - Supernova mount - 40 mm all sizes |
| Grip | MERIDA EXPERT EC |
| derailleur (r) | Sram GX Eagle |
| SHIFTER FRONT | Limotech RM10 (For SRAM MMX) |
| SHIFTER REAR | Sram GX Eagle Single Click |
| SEAT POST | MERIDA TEAM TR II - 34.9mm diameter - 0mm setback - SHORT,MID and XLONG 30.9 - 230mm travel seatpost - XSHORT 30.9 - 200mm travel seatpost |
| SEAT CLAMP | MERIDA EXPERT |
| Saddle | MERIDA COMP SL - 28% recycled material |
| PEDAL | VP VP-532 |
| Chain | Sram TX Eagle |
| CHAINWHEEL | Sram Eagle Transmission E-MTB chainring - 36 teeth |
| CRANK | Sram GX Eagle E-MTB Crank - 165mm all sizes |
| FREEWHEEL | Sram CS PG1230 EAGLE 11-50T |
| Rim | MERIDA EXPERT TR II - 110x15mm width front hub - 148x12mm width rear hub - 28mm inner width - material - aluminium - Tubeless ready (tubeless tape and valves not included) - for 29" |
| Tyre Front | Maxxis Assegai - 29x2.5" - fold - 3C TR MaxxGrip |
| Tyre Rear | Maxxis Minion DHR II - 27.5x2.4" - fold - 3C TR MaxxTerra |
| Hub Front | Shimano TC500 - 15x100mm width front hub - 32 spoke holes - Centerlock |
| Hub Rear | Shimano TC500 - 12x148mm width rear hub - 32 spoke holes - Centerlock |
| AXLE REAR | MERIDA EXPERT TR - including removable lever - 6/4mm allen key |
| SPOKES | black stainless |
| LIGHT FRONT | Lezyne Hecto StVZO E350+ Reverse - reverse MERIDA Custom Mount |
| LIGHT REAR | USR REAR Light CG-24RG |
| Battery Lock | Abus Key |
| DRIVE UNIT | Bosch Performance Line CX |
| Battery | Bosch PowerTube 800 Wh - removable |
| Display | Bosch Purion 400 |
| Approx. Weight | 27.0 kg - weighed at frame size M - Weight may vary depending on bike size - finish or possible specification changes due to supply chain issues. |
| Motor Brand | Bosch |
| Max Assisted Speed | 32km/h |
| Battery Brand | Bosch |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
