Bikeradar's Trail Bike of the Year 2023, the ONE-FORTY 700 marries a high-value all-aluminium frame to high-performance equipment that won't let you down. Our radical trail geometry delivers the sort of climbing ability that would make a mountain goat proud while shaming enduro bikes with descending speed. Wide range, 12-speed SRAM drivetrain and four-piston brakes, high-performance Marzocchi suspension plus our long travel adjustable dropper post deliver unwavering performance.
The test and award-winning ONE-FORTY is the ultimate trail bike, made for the toughest trails in the world. It’s the pinnacle of modern trail riding, with a super-steep 80° seat angle, low front end and bottom bracket allow it to clear the most technical climbs, while longer reach figures across all sizes and a well-balanced 65° head angle mean it’s still more than capable of ripping any descent. With our AGILOMETER sizing system, riders can run a longer or shorter reach frame independently of their height, with suspension that becomes more progressive as you size up to better cope with heavier/harder riders. We’ve focussed on weight reduction and rolling speed too, for improved efficiency. All bikes come with long travel dropper posts, WIRE PORT cable routing and a reliable threaded bottom bracket plus carbon frames have on-board tool storage and Fidlock magnetic bottle cages.
Features:
| crankset | Sram Eagle S1000 Eagle 32 ATC 170 mm for all sizes |
| bottom bracket | Sram BB DUB BSA 73 MTB WIDE |
| brakes | Sram DB8 stealth 4 piston |
| cassette | Sram PG-1210 Eagle 11-50 ATC 12 GER |
| chain | SRAM SX Eagle |
| derailleur rear | Sram NX Eagle |
| fork | Marzocchi Z1 Air 150 STR Tapered 44mm fork offset 29.5x2.6" max. WHS |
| frame | ONE-FORTY LITE III 143 STR 29" MAT aluminium 29x2.5" max. WHS 148x12 AST BSA BBR |
| grip | MERIDA EXPERT EC |
| handlebar | MERIDA EXPERT TR II MAT aluminium 780 WHB XS/S 18 RHB M/L/XL 30 RHB |
| handlebar stem | MERIDA EXPERT eTRII MAT aluminium 35 DSH 0 ASD |
| headset | Acros ICR MERIDA EXTERNAL neck Upper and lower IPS sealing |
| hubs | FRONT Shimano TC500-B 110x15 WHF 32 SPH Centerlock / REAR Shimano TC500-HM-B 148x12 WHR 32 SPH Centerlock |
| rim | MERIDA EXPERT TR II 110x15 WHF 148x12 WHR 28 IWR MAT aluminium Tubeless ready (tubeless tape and valves not included) 29" |
| rotor front | Sram CenterLine 200mm |
| rotor rear | Sram CenterLine 200mm |
| saddle | MERIDA COMP SL 25% recycled material V-mount incl. MERIDA minitool |
| season | 2025 |
| seat clamp | MERIDA EXPERT |
| seat post | MERIDA TEAM TR II 34.9 DSP 10 SSB all sizes 30-230 SPT |
| shock | Marzocchi Bomber Air Air platform |
| spokes | Double Butted Black stainless |
| tyre front | Maxxis Minion DHF 29x2.5" fold TR EXO 3C MaxxTera |
| tyre rear | Maxxis Dissector 29x2.4" fold TR EXO+ MaxxTerra |
| weight | 15.8 kg weighed at frame size M / Max Weight 135 kg Total weight of bike, rider and luggage |
| Crankset | Sram Eagle S1000 Eagle 32 ATC 170 mm for all sizes |
| Bottom Bracket | Sram BB DUB BSA 73 MTB WIDE |
| BRAKES | Sram DB8 stealth 4 piston |
| Cassette | Sram PG-1210 Eagle 11-50 ATC 12 GER |
| Chain | SRAM SX Eagle |
| DERAILLEUR REAR | Sram NX Eagle |
| Fork | Marzocchi Z1 Air 150 STR Tapered 44mm fork offset 29.5x2.6" max. WHS |
| FRAME | ONE-FORTY LITE III 143 STR 29" MAT aluminium 29x2.5" max. WHS 148x12 AST BSA BBR |
| Grip | MERIDA EXPERT EC |
| Handlebar | MERIDA EXPERT TR II MAT aluminium 780 WHB XS/S 18 RHB M/L/XL 30 RHB |
| HANDLEBAR STEM | MERIDA EXPERT eTRII MAT aluminium 35 DSH 0 ASD |
| Headset | Acros ICR MERIDA EXTERNAL neck Upper and lower IPS sealing |
| HUBS | FRONT Shimano TC500-B 110x15 WHF 32 SPH Centerlock / REAR Shimano TC500-HM-B 148x12 WHR 32 SPH Centerlock |
| Rim | MERIDA EXPERT TR II 110x15 WHF 148x12 WHR 28 IWR MAT aluminium Tubeless ready (tubeless tape and valves not included) 29" |
| ROTOR FRONT | Sram CenterLine 200mm |
| ROTOR REAR | Sram CenterLine 200mm |
| Saddle | MERIDA COMP SL 25% recycled material V-mount incl. MERIDA minitool |
| SEASON | 2025 |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | MERIDA TEAM TR II 34.9 DSP 10 SSB all sizes 30-230 SPT |
| Shock | Marzocchi Bomber Air Air platform |
| SPOKES | Double Butted Black stainless |
| Tyre Front | Maxxis Minion DHF 29x2.5" fold TR EXO 3C MaxxTera |
| Tyre Rear | Maxxis Dissector 29x2.4" fold TR EXO+ MaxxTerra |
| Weight | 15.8 kg weighed at frame size M / Max Weight 135 kg Total weight of bike, rider and luggage |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Groupset Model | GX Eagle |
| Fork Brand | Marzocchi |
| Fork Travel | 141 - 170mm |
| Shock Travel | 141 - 170mm |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Trail |
