XC LIGHT WITH TRAIL RIDING CAPABILITY
We made the Team Marin to be lightning-fast, super composed in the rough-and-tumble of spicy singletrack and perfectly in control up, along and down. It packs all the roll-up-your-sleeves tough of a trail bike and the zip you’d expect from an XC racer to perfectly blend speed with fun. Because who said XC had to be so serious?!
Champagne dreams on a cola budget. The Team Marin 1 brings XC-racer performance to a privateer price-point, all whilst staying super fun and super capable in the singletrack.
We started with a high-end Series 4 aluminum frame and fast-rolling 29” wheels and then added a capable RockShox Judy Silver fork, 12-speed Shimano drivetrain, Shimano hydraulic brakes and Vee Tire rubber to create a super fun, super affordable XC trail shredder.
| frame | All New Series 4 6061 Aluminum - 29" Wheels - Superlight Aluminum - Post-Mount Rear Brake - Internal Shifter and Dropper Post Routing - 148x12mm Boost Thru-Axle |
| front suspension | RockShox Judy Silver TK - 120mm Travel - Alloy Tapered Steerer - Solo Air Spring - 110x15mm Boost Spacing - Maxle Stealth - 51mm Offset |
| rim | Marin Aluminum Double Wall - 29mm Inner - Sleeve Joint - Disc Specific - Tubeless Compatible |
| hub rear | Forged Aluminum - 148x12mm - Disc Specific - 32H |
| hub front | Forged Aluminum - 110x15mm - Disc - 32H |
| spokes | 14g Black Stainless Steel |
| tires | Vee Tire - Rail Rocco XC - 29x2.3" - Dual Control Compound - Folding Bead - Tubeless Ready |
| derailleur rear | Shimano Deore - RDM6100 - 12-Speed |
| derailleur front | - |
| shift lever | Shimano Deore - SLM6100 - 12-Speed |
| crankset | Forged Alloy 1x12 - Hollow Spindle - Steel Narrow Wide 32T Chainring |
| brake levers | Shimano BL-MT201 |
| chain | KMC X12 |
| cassette | SunRace - 12-Speed - 11-51T |
| brakes front | Shimano BR-MT200 Hydraulic Disc - 180mm Rotor |
| brakes rear | Shimano BR-MT200 Hydraulic Disc - 160mm Rotor |
| handlebar | Marin Mini-Riser - 6061 Double Butted Aluminum - 780mm Width - 4º Up - 9º Back |
| stem | Marin 3D Forged Alloy - 35mm |
| grips | Marin Single Clamp Locking |
| headset | FSA No 42ACB - 1 1/8" x 1 1/2” |
| seatpost | Marin Alloy - 30.9mm |
| saddle | Marin Speed Concept |
| pedals | Nylon platform |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | Deore |
| Fork Brand | Rockshox |
| Fork Travel | 101 - 120mm |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Trail |
| FRAME | All New Series 4 6061 Aluminum - 29" Wheels - Superlight Aluminum - Post-Mount Rear Brake - Internal Shifter and Dropper Post Routing - 148x12mm Boost Thru-Axle |
| FRONT SUSPENSION | RockShox Judy Silver TK - 120mm Travel - Alloy Tapered Steerer - Solo Air Spring - 110x15mm Boost Spacing - Maxle Stealth - 51mm Offset |
| Rim | Marin Aluminum Double Wall - 29mm Inner - Sleeve Joint - Disc Specific - Tubeless Compatible |
| Hub Rear | Forged Aluminum - 148x12mm - Disc Specific - 32H |
| Hub Front | Forged Aluminum - 110x15mm - Disc - 32H |
| SPOKES | 14g Black Stainless Steel |
| Tires | Vee Tire - Rail Rocco XC - 29x2.3" - Dual Control Compound - Folding Bead - Tubeless Ready |
| DERAILLEUR REAR | Shimano Deore - RDM6100 - 12-Speed |
| DERAILLEUR FRONT | - |
| Shift Lever | Shimano Deore - SLM6100 - 12-Speed |
| Crankset | Forged Alloy 1x12 - Hollow Spindle - Steel Narrow Wide 32T Chainring |
| Brake Levers | Shimano BL-MT201 |
| Chain | KMC X12 |
| Cassette | SunRace - 12-Speed - 11-51T |
| Brakes Front | Shimano BR-MT200 Hydraulic Disc - 180mm Rotor |
| Brakes Rear | Shimano BR-MT200 Hydraulic Disc - 160mm Rotor |
| Handlebar | Marin Mini-Riser - 6061 Double Butted Aluminum - 780mm Width - 4º Up - 9º Back |
| Stem | Marin 3D Forged Alloy - 35mm |
| GRIPS | Marin Single Clamp Locking |
| Headset | FSA No 42ACB - 1 1/8" x 1 1/2” |
| Seatpost | Marin Alloy - 30.9mm |
| Saddle | Marin Speed Concept |
| PEDALS | Nylon platform |
