Polygon D6: Unlock Your Trail Potential
Ready to leave the pavement behind and conquer the dirt? The all-new Polygon D6 is your perfect gateway to the thrilling world of mountain biking. Engineered to be a supremely capable and confidence-inspiring entry-level dual-suspension bike, the D6 delivers premium features and modern trail geometry at an incredible value. Whether you're tackling local singletrack or exploring cross-country epics, the D6 is built to grow with you.
Float Over Obstacles
At the heart of the D6 is our lightweight and durable ALX XC Trail Frame, paired with a proven Suntour suspension package. The 120mm of travel, front and rear, smooths out rough terrain, soaking up rocks and roots so you can maintain control and comfort. The Suntour Raidon LO air rear shock provides excellent sensitivity, while the XCM 34 Boost fork keeps your front wheel planted. With adjustable rebound and a lockout feature for efficient climbing, this suspension setup gives you the versatility to master any part of the trail.
Modern, Reliable Performance
We've equipped the D6 with Shimano's revolutionary CUES drivetrain. This 1x10 speed system offers simplicity and incredible durability, with a massive 11−48T gear range that lets you spin up the steepest climbs and power through the flats. Shimano's MT200 hydraulic disc brakes provide consistent, powerful stopping power in all conditions, giving you the confidence to push your limits.
Descend with Confidence
A true game-changer at this level, the D6 comes standard with a TranzX dropper seatpost. With the push of a lever, you can drop your saddle out of the way for steep descents, increasing your stability and control when you need it most. Pop it back up for efficient pedaling on the climbs. It’s a feature that will transform your riding experience.
Who is this bike for?
The Polygon D6 is ideal for new riders looking for their first serious mountain bike, or for seasoned riders seeking a capable and affordable full-suspension machine. It's the perfect upgrade from a hardtail, offering more comfort, traction, and control to help you tackle more challenging terrain with ease.
| frame | ALX XC TRAIL FRAME |
| fork | SUNTOUR XCM 34 BOOST 120mm TRAVEL, PRELOAD ADJUSTER, LOCKOUT, REBOUND ADJUST, TAPERED 1-1/2 TO 1-1/8. 15x110mm W/ 15AH2-110 QLOC THRU AXLE |
| rear shock | SUNTOUR RAIDON LO AIR AIR SPRING, LOCKOUT METRIC 190x45mm |
| head tube i.d. | 44/56mm |
| hub spacing | 12x148mm |
| handlebar | POLYGON SPORT ALLOY 760mm, 31.8mm |
| handle stem | POLYGON SPORT ALLOY, 45mm, 31.8mm |
| saddle | LINC VOID SADDLE ø 7mm |
| seatpost | TRANZ X JD-YSP23KL 150mm TRAVEL. 30.9 x 456mm. 34.9mm clamp W/ BOLT |
| crankset | SHIMANO CUES FC-U6000-1 32T TWO-PIECE-CRANK |
| crankset - max chain ring | SINGLE 38T, DOUBLE 36/24T |
| crankset - crank arm | 170mm |
| pedal | PP pedal |
| bottom bracket | BSA THREADED 68/73MM |
| chain | KMC X GLIDE |
| cassette sprocket | SHIMANO CUES CS-LG300 11-48T 10-SPEED |
| front derailleur | - |
| rear derailleur | SHIMANO CUES RD-U6000 DIRECT ATTACH 10/11-SPEED |
| shifting lever | SHIMANO CUES SL-U6000, 10-SPEED TRIGGER |
| brakes | Shimano MT200 hydraulic disc brake |
| rotor | SHIMANO SM-RT10 F - 180mm / R - 160mm CENTER-LOCK |
| wheels | POLYGON MT6 TUBELESS READY W/ TUBELESS TAPE |
| rim | ALLOY DOUBLE WALL 584 / 622-24 32H FOR TYRE 584 / 622-35/68 |
| front hub | SHIMANO HB-TC500 THRU AXLE 15x110mm 32H CENTER LOCK |
| rear hub | SHIMANO FH-TC500 THRU AXLE 12X148mm 32H CENTER LOCK |
| tyre | DELI SPIDERBAIT 27.5"x2.25" |
| maximum tyre size | 27.5"x2.25" |
| FRAME | ALX XC TRAIL FRAME |
| Fork | SUNTOUR XCM 34 BOOST 120mm TRAVEL, PRELOAD ADJUSTER, LOCKOUT, REBOUND ADJUST, TAPERED 1-1/2 TO 1-1/8. 15x110mm W/ 15AH2-110 QLOC THRU AXLE |
| REAR SHOCK | SUNTOUR RAIDON LO AIR AIR SPRING, LOCKOUT METRIC 190x45mm |
| HEAD TUBE I.D. | 44/56mm |
| Hub Spacing | 12x148mm |
| Handlebar | POLYGON SPORT ALLOY 760mm, 31.8mm |
| HANDLE STEM | POLYGON SPORT ALLOY, 45mm, 31.8mm |
| Saddle | LINC VOID SADDLE ø 7mm |
| Seatpost | TRANZ X JD-YSP23KL 150mm TRAVEL. 30.9 x 456mm. 34.9mm clamp W/ BOLT |
| Crankset | SHIMANO CUES FC-U6000-1 32T TWO-PIECE-CRANK |
| CRANKSET - MAX CHAIN RING | SINGLE 38T, DOUBLE 36/24T |
| CRANKSET - CRANK ARM | 170mm |
| PEDAL | PP pedal |
| Bottom Bracket | BSA THREADED 68/73MM |
| Chain | KMC X GLIDE |
| Cassette Sprocket | SHIMANO CUES CS-LG300 11-48T 10-SPEED |
| Front Derailleur | - |
| Rear Derailleur | SHIMANO CUES RD-U6000 DIRECT ATTACH 10/11-SPEED |
| SHIFTING LEVER | SHIMANO CUES SL-U6000, 10-SPEED TRIGGER |
| BRAKES | Shimano MT200 hydraulic disc brake |
| Rotor | SHIMANO SM-RT10 F - 180mm / R - 160mm CENTER-LOCK |
| Wheels | POLYGON MT6 TUBELESS READY W/ TUBELESS TAPE |
| Rim | ALLOY DOUBLE WALL 584 / 622-24 32H FOR TYRE 584 / 622-35/68 |
| FRONT HUB | SHIMANO HB-TC500 THRU AXLE 15x110mm 32H CENTER LOCK |
| REAR HUB | SHIMANO FH-TC500 THRU AXLE 12X148mm 32H CENTER LOCK |
| Tyre | DELI SPIDERBAIT 27.5"x2.25" |
| Maximum tyre size | 27.5"x2.25" |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | CUES |
| Fork Brand | Suntour |
| Fork Travel | 101 - 120mm |
| Shock Travel | 101 - 120mm |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 1 x 10 |
| Ride Style | Cross Country |
