The new frame design on Fuel lets most size M riders run a 200mm dropper
Tons of room for big water bottles, spare tubes, or additional accessories like frame bags or mini-pumps
Fuel now utilizes the ZS internal headset standard to allow for more aftermarket options like angle-adjust headsets or shiny colors.
Riders can tweak leverage rate with the flip of a chip. Go less progressive for a plusher feel or more progressive for big features, more bottom out resistance, or running a coil shock.
The Fuel EX 8 is a confident and versatile trail bike built to get after it. It comes ready to rip with an Alpha NEXT Platinum frame, Fox performance suspension package with 145 mm/150 mm travel (rear, front), alloy Bontrager Line wheels and a SRAM Eagle 70 transmission that keeps shifts smooth, even under load. It's topped off with 4-piston SRAM DB 8 hydraulic disc brakes to keep you stopping on a penny.
Fuel EX has always been our most versatile full-suspension bike, giving riders an award-winning trail feel wherever they roll. Now, Fuel has been updated with a new frame design that maximizes versatility without any compromises on performance.
With interchangeable rocker links and lower shock mounts, the all-new Fuel transforms into three configurations, adapting to different terrain and riding styles, so you can dial in your customer no matter how they ride or where they roll.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| tire | Size - S, XL, L, M - Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.50", Size - S - Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.50" |
| max tyre size | Frame - 29x2.50", Fork - See manufacturer |
| max chainring size | Max - 34T (oval – 32T) Min - 30T (oval – 32T) |
| seatpost | Size - S - Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length, Size - M - Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length, Size - XL, L - Bontrager Line Dropper, 200 mm travel, |
| rotor size | Max brake rotor sizes – Frame - 203 mm, min 180 mm, Fork - see fork manufacturer |
| weight | M - 16.89 kg / 37.24 lbs (with TLR sealant, no tubes) |
| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| mainframe | Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, |
| fork | Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt X axle, 150 mm travel |
| shock | Fox Performance Float X, 2-position damper, 205 mm x 60 mm |
| front hub | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle |
| rear skewer | Bontrager Switch thru-axle, removable lever |
| rim | Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve |
| tire part | Bontrager TLR sealant, 180 ml/6 oz |
| rim strip | Bontrager TLR |
| shifter | SRAM Eagle 70, 12-speed |
| rear derailleur | SRAM Eagle 70, T-Type |
| crank | SRAM Eagle 70, DUB, 30T steel, T-Type, 55 mm chainline, 170 mm length |
| bottom bracket | SRAM DUB MTB Wide, 73 m, BSA threaded |
| cassette | SRAM Eagle XS-1270, T-Type,10-52, 12-speed |
| chain | SRAM Eagle 70, T-Type, 12-speed |
| saddle | Bontrager Verse P3, chromoly rails |
| handlebar | Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width |
| grips | Trek Line Comp, nylon lock-on |
| stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| headset | FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown |
| brake | SRAM DB 8 4-piston hydraulic disc |
| brake rotor | SRAM CenterLine 2.0, 6-bolt, 180 mm, Size - S, XL, L, M - SRAM CenterLine 2.0, 6-bolt, 200 mm |
| Massive dropper insertion | The new frame design on Fuel lets most size M riders run a 200mm dropper |
| Open triangle | Tons of room for big water bottles, spare tubes, or additional accessories like frame bags or mini-pumps |
| ZS standard headset | Fuel now utilizes the ZS internal headset standard to allow for more aftermarket options like angle-adjust headsets or shiny colors. |
| Leverage rate adjust | Riders can tweak leverage rate with the flip of a chip. Go less progressive for a plusher feel or more progressive for big features, more bottom out resistance, or running a coil shock. |
| Frame Material | Alloy |
| Fork Material | Alloy |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Groupset Model | Eagle 70 |
| Fork Brand | Fox |
| Fork Travel | 141 - 170mm |
| Shock Travel | 171 - 220mm |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Trail |
| TIRE | Size - S, XL, L, M - Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.50", Size - S - Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.50" |
| MAX TYRE SIZE | Frame - 29x2.50", Fork - See manufacturer |
| MAX CHAINRING SIZE | Max - 34T (oval – 32T) Min - 30T (oval – 32T) |
| Seatpost | Size - S - Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length, Size - M - Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length, Size - XL, L - Bontrager Line Dropper, 200 mm travel, |
| Rotor size | Max brake rotor sizes – Frame - 203 mm, min 180 mm, Fork - see fork manufacturer |
| Weight | M - 16.89 kg / 37.24 lbs (with TLR sealant, no tubes) |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| Mainframe | Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, |
| Fork | Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt X axle, 150 mm travel |
| Shock | Fox Performance Float X, 2-position damper, 205 mm x 60 mm |
| FRONT HUB | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle |
| Rear skewer | Bontrager Switch thru-axle, removable lever |
| Rim | Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve |
| Tire part | Bontrager TLR sealant, 180 ml/6 oz |
| Rim strip | Bontrager TLR |
| Shifter | SRAM Eagle 70, 12-speed |
| Rear Derailleur | SRAM Eagle 70, T-Type |
| CRANK | SRAM Eagle 70, DUB, 30T steel, T-Type, 55 mm chainline, 170 mm length |
| Bottom Bracket | SRAM DUB MTB Wide, 73 m, BSA threaded |
| Cassette | SRAM Eagle XS-1270, T-Type,10-52, 12-speed |
| Chain | SRAM Eagle 70, T-Type, 12-speed |
| Saddle | Bontrager Verse P3, chromoly rails |
| Handlebar | Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width |
| GRIPS | Trek Line Comp, nylon lock-on |
| Stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| Headset | FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown |
| BRAKE | SRAM DB 8 4-piston hydraulic disc |
| BRAKE ROTOR | SRAM CenterLine 2.0, 6-bolt, 180 mm, Size - S, XL, L, M - SRAM CenterLine 2.0, 6-bolt, 200 mm |
