Washboard descents, sketchy dirt, gravel and rocks of all shapes and sizes. You never know what you’ll get on a gravel ride. This composite gravel machine has front suspension and engineered compliance to help you float through it all with speed and control.
Composite frameset is designed specifically for front suspension. With 40mm of travel, the fork absorbs impacts so you can ride smoother and faster on rugged gravel and dirt.
Lowered seatstays with smaller diameter tubes absorb road shocks and vibrations. A Contact SL XR D-Fuse handlebar adds more compliance without sacrificing the stiffness needed for cornering, sprinting or climbing.
A flip chip on the rear dropout adjusts the wheelbase short for quicker handling, or long for improved stability at speed. The long setting also allows for larger diameter tyres up to 53mm.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | Advanced-Grade Composite, 12x142mm thru-axle, disc, flip chip dropout |
| fork | Fox 32 Float TC, Performance Elite, 40mm, FIT 4 damper, 12x100mm Kabolt thru-axle |
| gear shifters | SRAM Rival AXS E1, 1x12 |
| chainset | SRAM Rival XPLR E1 DUB, 40T, XS - 170mm, S - 170mm, M - 172.5mm, M/L - 172.5mm, L - 175mm, XL - 175mm |
| chainrings | 40t |
| rear cassette | SRAM XG-1275, 12-speed, 10x52 |
| chain | Sram GX Eagle |
| front derailleur | N/A |
| rear derailleur | SRAM GX Eagle AXS |
| bottom bracket | SRAM DUB, press fit |
| rims | Giant CXR 1 X1 WheelSystem, [F]25.8mm, [R]25.8mm |
| front hub | Giant CXR X alloy, CenterLock, 12mm thru-axle |
| rear hub | Giant CXR X alloy, 60T ratchet driver, CenterLock, 12mm thru-axle |
| front tyre | Giant CrossCut Grip, tubeless, 700x45c |
| rear tyre | Giant CrossCut Grip, tubeless, 700x45c |
| brakes | SRAM Rival AXS E1 hydraulic, SRAM PaceLine rotors, [F]160mm, [R]160mm |
| handlebars | Giant Contact SL XR D-Fuse, 31.8mm, XS - 440mm, S - 440mm, M - 460mm, M/L - 460mm, L - 480mm, XL - 480mm |
| handlebar tape | Giant Stratus |
| stem | Giant Contact, 8-degree, XS - 50mm, S - 50mm, M - 60mm, M/L - 70mm, L - 70mm, XL - 80mm |
| saddle | Giant Grit SL |
| seatpost | Post Moderne, dropper, 30.9mm with 30mm suspension, XS - 365mm/75mm drop, S - 415mm/100mm drop |
| accessories | Tubeless prepared, flip chip adjustable geometry, 53mm max tyre clearance (long position) |
| FRAME | Advanced-Grade Composite, 12x142mm thru-axle, disc, flip chip dropout |
| Fork | Fox 32 Float TC, Performance Elite, 40mm, FIT 4 damper, 12x100mm Kabolt thru-axle |
| Gear Shifters | SRAM Rival AXS E1, 1x12 |
| Chainset | SRAM Rival XPLR E1 DUB, 40T, XS - 170mm, S - 170mm, M - 172.5mm, M/L - 172.5mm, L - 175mm, XL - 175mm |
| CHAINRINGS | 40t |
| Rear Cassette | SRAM XG-1275, 12-speed, 10x52 |
| Chain | Sram GX Eagle |
| Front Derailleur | N/A |
| Rear Derailleur | SRAM GX Eagle AXS |
| Bottom Bracket | SRAM DUB, press fit |
| RIMS | Giant CXR 1 X1 WheelSystem, [F]25.8mm, [R]25.8mm |
| FRONT HUB | Giant CXR X alloy, CenterLock, 12mm thru-axle |
| REAR HUB | Giant CXR X alloy, 60T ratchet driver, CenterLock, 12mm thru-axle |
| FRONT TYRE | Giant CrossCut Grip, tubeless, 700x45c |
| REAR TYRE | Giant CrossCut Grip, tubeless, 700x45c |
| BRAKES | SRAM Rival AXS E1 hydraulic, SRAM PaceLine rotors, [F]160mm, [R]160mm |
| HANDLEBARS | Giant Contact SL XR D-Fuse, 31.8mm, XS - 440mm, S - 440mm, M - 460mm, M/L - 460mm, L - 480mm, XL - 480mm |
| HANDLEBAR TAPE | Giant Stratus |
| Stem | Giant Contact, 8-degree, XS - 50mm, S - 50mm, M - 60mm, M/L - 70mm, L - 70mm, XL - 80mm |
| Saddle | Giant Grit SL |
| Seatpost | Post Moderne, dropper, 30.9mm with 30mm suspension, XS - 365mm/75mm drop, S - 415mm/100mm drop |
| Accessories | Tubeless prepared, flip chip adjustable geometry, 53mm max tyre clearance (long position) |
| Frame Material | Carbon |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Groupset Model | Rival AXS |
| Fork Brand | Fox |
| Shifting Type | Electronic |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Gravel |
Ordering a bike from Evo? If you choose the option Evo Home Delivery at the checkout your order will be personally delivered to you, by an Evo Crew Member, who will also be able to answer any questions you have about your new bike. If you choose Evo Delivery your bike will be delivered completely built, tuned and ready to ride! We are also able to offer Evo Home Delivery on previously restricted brands such as Giant & Trek!
Our home delivery charge is only $30 for 15km and $1 per km after that.
Free for all orders over $99. Orders under $99 a $6.99 flat shipping & handling fee applies. Order and pay online and collect everything from one of our showrooms. Just select which store you would like to collect from at checkout. Find out more about Click & Collect here.
LEARN MORE
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
