The Fuel EX 9.8 Eagle 90 is a versatile and adaptable carbon MTB built to tackle any trail, at any time. Its OCLV Mountain Carbon frame pairs with a RockShox Lyrik Ultimate fork and Deluxe Ultimate RC2T shock (150 mm front, 145 mm rear) for confident handling on any trail. A SRAM Eagle 90 transmission gives you fuss-free mechanical shifting that stays smooth under load, while SRAM Maven Bronze 4-piston brakes deliver incredible power for quick stops after steep descents.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | OCLV Mountain Carbon, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable trav |
| fork | RockShox Lyrik Ultimate, DebonAir+ w/ ButterCups, Charger 3.1 RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel |
| shock | RockShox Deluxe Ultimate RC2T, 205 mm x 60 mm |
| wheel front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" |
| wheel rear | Bontrager Line Comp 30, Tubeless-Ready, Rapid Drive 108, 6-bolt, SRAM XD freehub, Boost148, 12 mm thru axle, 29'' |
| skewer rear | Bontrager Switch thru-axle, removable lever |
| tyre size xl | Maxxis Minion DHF, tubeless-ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5'' |
| tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| rear derailleur | SRAM Eagle 90, T-Type |
| crank | SRAM Eagle 90, DUB, 30T steel, T-Type, 55 mm chainline, 170 mm length |
| bottom bracket | SRAM DUB MTB Wide, 73 m, BSA threaded |
| cassette | SRAM Eagle XS-1275, T-Type, 10-52, 12-speed |
| chain | SRAM GX Eagle, T-Type, 12-speed |
| saddle | Verse Short Pro, carbon rails, 145 mm width |
| seatpost | Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length |
| handlebar | Race Face ERA, carbon, 35 mm, 27.5 mm rise, 800 mm width |
| grips | Trek Line Elite, lock-on |
| stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| brake | SRAM Maven Bronze 4-piston hydraulic disc |
| weight | M - 15.38 kg / 33.91 lbs (with TLR sealant, no tubes) |
| weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| Frame Material | Carbon |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Fork Brand | Rockshox |
| Fork Travel | 141 - 170mm |
| Shock Travel | 141 - 170mm |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Trail |
| FRAME | OCLV Mountain Carbon, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable trav |
| Fork | RockShox Lyrik Ultimate, DebonAir+ w/ ButterCups, Charger 3.1 RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel |
| Shock | RockShox Deluxe Ultimate RC2T, 205 mm x 60 mm |
| Wheel Front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" |
| Wheel Rear | Bontrager Line Comp 30, Tubeless-Ready, Rapid Drive 108, 6-bolt, SRAM XD freehub, Boost148, 12 mm thru axle, 29'' |
| Skewer rear | Bontrager Switch thru-axle, removable lever |
| Tyre Size XL | Maxxis Minion DHF, tubeless-ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5'' |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Rear Derailleur | SRAM Eagle 90, T-Type |
| CRANK | SRAM Eagle 90, DUB, 30T steel, T-Type, 55 mm chainline, 170 mm length |
| Bottom Bracket | SRAM DUB MTB Wide, 73 m, BSA threaded |
| Cassette | SRAM Eagle XS-1275, T-Type, 10-52, 12-speed |
| Chain | SRAM GX Eagle, T-Type, 12-speed |
| Saddle | Verse Short Pro, carbon rails, 145 mm width |
| Seatpost | Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length |
| Handlebar | Race Face ERA, carbon, 35 mm, 27.5 mm rise, 800 mm width |
| GRIPS | Trek Line Elite, lock-on |
| Stem | Bontrager Elite, 35 mm, 0-degree, 45 mm length |
| BRAKE | SRAM Maven Bronze 4-piston hydraulic disc |
| Weight | M - 15.38 kg / 33.91 lbs (with TLR sealant, no tubes) |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
