The Marin DSX 1 Flat Bar Gravel Bike in Green/Silver is designed for those who crave adventure on varied terrains. With its lightweight alloy frame and carbon fork, this bike offers a perfect blend of durability and comfort, making it ideal for both casual rides and challenging gravel paths. Equipped with hydraulic disc brakes, it ensures reliable stopping power, while the 11-speed drivetrain provides smooth gear transitions. Whether you're commuting or exploring, the Marin DSX 1 is ready to take you wherever the road leads.
Features:
| frame | Series 2 DSX, 6061 Aluminum, Internal Cable Routing, Mudguard and Rack Mounts, IS Disc Mount |
| fork | Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets |
| rims | Marin Aluminum Double Wall, Disc Specific |
| hub, rear | Forged Aluminum Alloy, Disc, 32H |
| hub, front | Forged Aluminum Alloy, Disc, 32H |
| spoke, nipples nipples | 14g Black Stainless Steel |
| tires | WTB Riddler, 700Cx45mm |
| derailleur, rear | Tektro Gemini, SL-M5100, 11-speed |
| shift lever | Tektro Gemini, SL-M5100, 11-speed |
| crankset | Forged Alloy 1x11, Hollow Spindle, Steel Narrow Wide 42T Chainring |
| bottom bracket | Sealed Cartridge Bearings, Square Taper |
| chain | KMC X9 |
| cassette | Tektro Gemini,, CS-M5100, 11-Speed, 11-50T |
| brake, front | Tektro HD-R285 Flat Mount Hydraulic , 160mm Rotor |
| brake, rear | Tektro HD-R285 Flat Mount Hydraulic , 160mm Rotor |
| brake levers | Tektro Hydraulic |
| handlebar | Marin Mini Riser |
| stem | Marin 3D Forged Alloy |
| grips | Marin MTB |
| headset | FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” |
| seatpost | Marin Alloy |
| saddle | Marin DSX |
| pedals | Nylon platform |
| FRAME | Series 2 DSX, 6061 Aluminum, Internal Cable Routing, Mudguard and Rack Mounts, IS Disc Mount |
| Fork | Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets |
| RIMS | Marin Aluminum Double Wall, Disc Specific |
| HUB, REAR | Forged Aluminum Alloy, Disc, 32H |
| HUB, FRONT | Forged Aluminum Alloy, Disc, 32H |
| SPOKE, NIPPLES NIPPLES | 14g Black Stainless Steel |
| Tires | WTB Riddler, 700Cx45mm |
| DERAILLEUR, REAR | Tektro Gemini, SL-M5100, 11-speed |
| Shift Lever | Tektro Gemini, SL-M5100, 11-speed |
| Crankset | Forged Alloy 1x11, Hollow Spindle, Steel Narrow Wide 42T Chainring |
| Bottom Bracket | Sealed Cartridge Bearings, Square Taper |
| Chain | KMC X9 |
| Cassette | Tektro Gemini,, CS-M5100, 11-Speed, 11-50T |
| BRAKE, FRONT | Tektro HD-R285 Flat Mount Hydraulic , 160mm Rotor |
| BRAKE, REAR | Tektro HD-R285 Flat Mount Hydraulic , 160mm Rotor |
| Brake Levers | Tektro Hydraulic |
| Handlebar | Marin Mini Riser |
| Stem | Marin 3D Forged Alloy |
| GRIPS | Marin MTB |
| Headset | FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” |
| Seatpost | Marin Alloy |
| Saddle | Marin DSX |
| PEDALS | Nylon platform |
| Frame Material | Alloy |
| Fork Material | Carbon |
| Brake Type | Hydraulic Disc Brake |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 1 x 11 |
| Ride Style | Gravel |
On all orders over $99 Evo Cycles offers free delivery to any non-rural address in New Zealand* - this includes large / bulky items and bike brands that are able to be shipped**
On orders under $99 we charge $6.99 fee for non-rural addresses and $11.99 for rural addresses. This is so we can give our customers (that's you!) the most competitive pricing available for small parts and accessories. There are no hidden shipping costs and you know exactly what you're paying for.
*There is an additional $5 charge for all rural deliveries.
Ordering a bike from Evo? If you choose the option Evo Home Delivery at the checkout your order will be personally delivered to you, by an Evo Crew Member, who will also be able to answer any questions you have about your new bike. If you choose Evo Delivery your bike will be delivered completely built, tuned and ready to ride! We are also able to offer Evo Home Delivery on previously restricted brands such as Giant & Trek!
Our home delivery charge is only $30 for 15km and $1 per km after that.
Free for all orders over $99. Orders under $99 a $6.99 flat shipping & handling fee applies. Order and pay online and collect everything from one of our showrooms. Just select which store you would like to collect from at checkout. Find out more about Click & Collect here.
LEARN MORE
* All specifications listed are subject to change without notice. Please note that our specifications may be impacted by manufacturer component substitution changes caused by high global demand for bikes and resulting supply chain issues in the bike industry. We recommend confirming the specifications with your local Evo Cycles showroom if you have any questions.
Bike Weight: Many brands strive to list the lowest possible weight, but in reality weight can vary based on frame size, finish, hardware and accessories. The most accurate way to determine any bike's weight is to have your local showroom weigh it for you.
