The power to do more of what matters. That's what the eBIG.NINE 400 EQ offers. More fun when you're riding off-road, with a powerful new Shimano EP6 drive unit to help you up the hills. More versatility, thanks to a fully equipped spec that includes lights, mudguards, lock, rack and kickstand. More time on the bike, with a 630 Wh battery that'll keep you going for miles. More control, thanks to a SR Suntour suspension fork, chunky tyres and powerful Shimano brakes. More comfort on the commute, thanks to standard fit mudguards, lights, rack and kickstand. More of everything except unnecessary weight, thanks to a high-quality aluminium frame that's also got a lifetime warranty.
Arguably the most versatile e-bike in our range, the tried and tested eBIG.NINE embodies the perfect balance of day-to-day usability and sporty leisure activity. It's a bike that can handle serious off-road riding but can also handle the commute to work with ease - especially if you want to have some fun on the way. The high-quality aluminium frame integrates a 630Wh battery sleekly into the downtube. All feature powerful and smooth Shimano drive units that will power you up any hill. Ready to be equipped with mudguards and even a side stand (or available as the EQ fully equipped version), the eBIG.NINE will help you make the most of any situation.
Features:
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| battery | Shimano EN806, 630Wh |
| brakes | Shimano MT-200, 2 piston |
| cassette | Shimano LG300, 11-48,10, |
| chain | Shimano LG500, |
| colour | Metallic Black(Gunmetal Grey) |
| crankset | Shimano CRE70-B, 34t; Shimano FC-EM600, 165 mm for all sizes |
| derailleur rear | Shimano CUES U6000, GS |
| display | Shimano SC-EN500A, |
| fork | Suntour XCM34-Boost LOR DS, 100mm, Tapered, 51mm fork offset, 29x2.4" max WHS, |
| frame | eBIG.NINE LITE III, MAT aluminium, 29x2.35" without fender max./ 29"x2.25" with fender max. WHS, 148x12 AST, intube, |
| grip | MERIDA COMP TK, |
| handlebar | MERIDA EXPERT CC, MAT aluminium, 720 WHB, 10 RHB |
| handlebar stem | MERIDA EXPERT CT, MAT aluminium, 31.8 DSH, adjustable; 90 mm all sizes, |
| headset | MERIDA-8155 (for the steerer 1-1/8"~1.5"), |
| motor drive unit | Shimano EP6, 85Nm |
| pedals | VP VPE-537, |
| rim | MERIDA COMP CC II, 25 IWR, MAT aluminium, |
| rotor front | Shimano RT30, 180 mm |
| rotor rear | Shimano RTEM300, 180 mm |
| saddle | MERIDA EXPERT TK, V-mount |
| season | 2026 |
| seat clamp | MERIDA EXPERT, |
| seat post | MERIDA EXPERT CC, MAT aluminium, 34.9 DSP, 0 SSB |
| shifters | Shimano CUES U6000-11, |
| Battery | Shimano EN806, 630Wh |
| BRAKES | Shimano MT-200, 2 piston |
| Cassette | Shimano LG300, 11-48,10, |
| Chain | Shimano LG500, |
| COLOUR | Metallic Black(Gunmetal Grey) |
| Crankset | Shimano CRE70-B, 34t; Shimano FC-EM600, 165 mm for all sizes |
| DERAILLEUR REAR | Shimano CUES U6000, GS |
| Display | Shimano SC-EN500A, |
| Fork | Suntour XCM34-Boost LOR DS, 100mm, Tapered, 51mm fork offset, 29x2.4" max WHS, |
| FRAME | eBIG.NINE LITE III, MAT aluminium, 29x2.35" without fender max./ 29"x2.25" with fender max. WHS, 148x12 AST, intube, |
| Grip | MERIDA COMP TK, |
| Handlebar | MERIDA EXPERT CC, MAT aluminium, 720 WHB, 10 RHB |
| HANDLEBAR STEM | MERIDA EXPERT CT, MAT aluminium, 31.8 DSH, adjustable; 90 mm all sizes, |
| Headset | MERIDA-8155 (for the steerer 1-1/8"~1.5"), |
| Motor drive unit | Shimano EP6, 85Nm |
| PEDALS | VP VPE-537, |
| Rim | MERIDA COMP CC II, 25 IWR, MAT aluminium, |
| ROTOR FRONT | Shimano RT30, 180 mm |
| ROTOR REAR | Shimano RTEM300, 180 mm |
| Saddle | MERIDA EXPERT TK, V-mount |
| SEASON | 2026 |
| SEAT CLAMP | MERIDA EXPERT, |
| SEAT POST | MERIDA EXPERT CC, MAT aluminium, 34.9 DSP, 0 SSB |
| Shifters | Shimano CUES U6000-11, |
| Frame Material | Alloy |
| Fork Material | Alloy |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | CUES |
| Fork Brand | Suntour |
| Motor Brand | Shimano |
| Battery Brand | Shimano |
| Motor Type | Mid-Drive Motor |
| Frame Style | Step-Over |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 1 x 10 |
| Ride Style | Trail |
