With hydraulic disc brakes, an easy-to-use single ring drivetrain, our latest TFS aluminium frame and a trail-ready 120 mm travel fork, the BIG.NINE 20 is ready to ride. Whether you need a versatile bike for weekend trail fun or a rugged way to get about, the smooth-rolling 29" wheels and updated, confidence-inspiring geometry will have you covered.
When it comes to the demanding world of cross-country mountain biking, the classic hardtail remains one of the purest tools for the job. Our 29er wheel equipped BIG.NINE range comes with the choice of carbon or two different aluminium frames to deliver a ride for all budgets. The latest CF carbon and LITE aluminium framed BIG.NINE offer truly modern geometry with increased standover clearance and handling stability to better deal with the tough race tracks of today. They also have downcountry ready TR options that boost fork travel and add in aggressive tyres and dropper posts. For riders starting out, the updated BIG.NINE TFS offers more relaxed geometry and builds that deliver great value and versatility on or off the trail, with BIG.SEVEN TFS models using 27.5" wheels to deliver a fit for for shorter riders. Our classic XC hardtails are the backbone of our range and showcase the enormous wealth of experience and knowledge we have gained in over half a century of bike production and manufacturing. The BIG.NINE range represents the symbiosis between modern frame technology, attention to detail and craftsmanship that 'Made in Taiwan' stands for.
Features:
| frame | BIG.NINE TFS V, MAT aluminum, 29 WHS, 135x9 AST, BSA BBR, |
| fork | SR Suntour XCM32 NLO, Coil, 120 STR, lockout, 29x2,4" max. WHS, |
| brake front | Shimano MT200, hydraulic brake |
| brake rear | Shimano MT200, hydraulic brake |
| rotor front | Shimano RT10, 160 mm |
| rotor rear | Shimano RT10, 160 mm |
| chain | KMC Z8.3, |
| crankset | Prowheel Epro-MD26S, 32t, MAT Aluminium, |
| bottom bracket | Shimano UN101 LL123, |
| derailleur front | 0, |
| derailleur rear | Shimano Essa RD-U2000-8, GS |
| cassette | Shimano CS-HG300-8, 11-45t, 8sp |
| pedal | VP VPE 536, |
| grip | MERIDA EC, |
| stem | MERIDA COMP CC, MAT aluminium, 31.8 DSH, 7 ASD |
| headset | FSA NO.55R/57SC/57B, |
| hub front | Shimano QC300, 100x9 WHF, 32 SPH, Centerlock |
| hub rear | Shimano QC300-HM, 135x9 WHR, 32 SPH, Centerlock |
| rim | MERIDA COMP CC, 20 IWR, MAT aluminium, |
| saddle | MERIDA Sport comfort, |
| seat clamp | MERIDA COMP QR, |
| seat post | MERIDA COMP CC, MAT aluminium, 30.9 DSP, 0 SSB |
| shifter front | 0, |
| shifter rear | Shimano Essa SL-315-8R, |
| tyre front | Kenda Booster, 29x2.4", |
| tyre rear | Kenda Booster, 29x2.4", |
| FRAME | BIG.NINE TFS V, MAT aluminum, 29 WHS, 135x9 AST, BSA BBR, |
| Fork | SR Suntour XCM32 NLO, Coil, 120 STR, lockout, 29x2,4" max. WHS, |
| Brake Front | Shimano MT200, hydraulic brake |
| Brake Rear | Shimano MT200, hydraulic brake |
| ROTOR FRONT | Shimano RT10, 160 mm |
| ROTOR REAR | Shimano RT10, 160 mm |
| Chain | KMC Z8.3, |
| Crankset | Prowheel Epro-MD26S, 32t, MAT Aluminium, |
| Bottom Bracket | Shimano UN101 LL123, |
| DERAILLEUR FRONT | 0, |
| DERAILLEUR REAR | Shimano Essa RD-U2000-8, GS |
| Cassette | Shimano CS-HG300-8, 11-45t, 8sp |
| PEDAL | VP VPE 536, |
| Grip | MERIDA EC, |
| Stem | MERIDA COMP CC, MAT aluminium, 31.8 DSH, 7 ASD |
| Headset | FSA NO.55R/57SC/57B, |
| Hub Front | Shimano QC300, 100x9 WHF, 32 SPH, Centerlock |
| Hub Rear | Shimano QC300-HM, 135x9 WHR, 32 SPH, Centerlock |
| Rim | MERIDA COMP CC, 20 IWR, MAT aluminium, |
| Saddle | MERIDA Sport comfort, |
| SEAT CLAMP | MERIDA COMP QR, |
| SEAT POST | MERIDA COMP CC, MAT aluminium, 30.9 DSP, 0 SSB |
| SHIFTER FRONT | 0, |
| SHIFTER REAR | Shimano Essa SL-315-8R, |
| Tyre Front | Kenda Booster, 29x2.4", |
| Tyre Rear | Kenda Booster, 29x2.4", |
| Frame Material | Alloy |
| Fork Material | Alloy |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | ESSA |
| Fork Brand | Suntour |
| Fork Travel | 101 - 120mm |
| Shock Travel | 101 - 120mm |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 1 x 8 |
| Ride Style | Trail |
