Everything you need to tackle the trails. The BIG.NINE 200 uses our updated TFS aluminium frame, with confidence-inspiring geometry, fast-rolling 29" wheels and a 120 mm air-sprung fork to take care of the bumps. Shimano provides powerful hydraulic disc brakes while the wide gear range CUES 1x10-speed drivetrain is easy to use and will get you up any hill.
When it comes to the demanding world of cross-country mountain biking, the classic hardtail remains one of the purest tools for the job. Our 29er wheel equipped BIG.NINE range comes with the choice of carbon or two different aluminium frames to deliver a ride for all budgets. The latest CF carbon and LITE aluminium framed BIG.NINE offer truly modern geometry with increased standover clearance and handling stability to better deal with the tough race tracks of today. They also have downcountry ready TR options that boost fork travel and add in aggressive tyres and dropper posts. For riders starting out, the updated BIG.NINE TFS offers more relaxed geometry and builds that deliver great value and versatility on or off the trail, with BIG.SEVEN TFS models using 27.5" wheels to deliver a fit for for shorter riders. Our classic XC hardtails are the backbone of our range and showcase the enormous wealth of experience and knowledge we have gained in over half a century of bike production and manufacturing. The BIG.NINE range represents the symbiosis between modern frame technology, attention to detail and craftsmanship that 'Made in Taiwan' stands for.
Features:
| frame | BIG.NINE TFS V, MAT aluminum, 29 WHS, 135x9 AST, BSA BBR, Smooth welding |
| shock | N/A |
| fork | Suntour XCR32 Boost LOR, Air, 120 STR, 27.5x2.5" max. WHS, Lockout, 42mm fork offset |
| brake front | Shimano MT200, 2 piston |
| brake rear | Shimano MT200, 2 piston |
| rotor front | Shimano RT10, 180mm |
| rotor rear | Shimano RT10, 160mm |
| chain | KMC xGlide |
| crankset | Shimano CUES U6000, 32t |
| crank length | 165mm |
| bb set | Shimano MT500 |
| derailleur front | n/a |
| derailleur rear | Shimano CUES U6000, GS |
| hub front | Shimano TC500-B, 110x15 WHF, 32 SPH, Centerlock |
| pedal | VP VPE-891 |
| grip | MERIDA Comp EC |
| handlebar | MERIDA EXPERT CC, MAT aluminium, XXS/XS- 700WHB, S 720 WHB, 10 RHB |
| stem | MERIDA COMP CC, MAT aluminium, 31.8 DSH, 7 ASD |
| stem size | 50mm |
| headset | FSA NO.55R/57SC/57B |
| hub rear | Shimano QC300-HM, 135x9 WHR, 32 SPH, Centerlock |
| rim | MERIDA COMP CC II, 25 IWR, MAT aluminium, tubeless ready |
| saddle | MERIDA COMP SL, V-mount |
| seat clamp | MERIDA comp QR |
| seat post | MERIDA COMP CC, MAT aluminium, 30.9 DSP, 0 SSB |
| shifter front | N/A |
| shifter rear | Shimano CUES U6000 |
| tyre front | Kenda Booster, 27.5"x2.4, wired |
| tyre rear | Kenda Booster, 27.5"x2.4, wired |
| FRAME | BIG.NINE TFS V, MAT aluminum, 29 WHS, 135x9 AST, BSA BBR, Smooth welding |
| Shock | N/A |
| Fork | Suntour XCR32 Boost LOR, Air, 120 STR, 27.5x2.5" max. WHS, Lockout, 42mm fork offset |
| Brake Front | Shimano MT200, 2 piston |
| Brake Rear | Shimano MT200, 2 piston |
| ROTOR FRONT | Shimano RT10, 180mm |
| ROTOR REAR | Shimano RT10, 160mm |
| Chain | KMC xGlide |
| Crankset | Shimano CUES U6000, 32t |
| Crank Length | 165mm |
| BB Set | Shimano MT500 |
| DERAILLEUR FRONT | n/a |
| DERAILLEUR REAR | Shimano CUES U6000, GS |
| Hub Front | Shimano TC500-B, 110x15 WHF, 32 SPH, Centerlock |
| PEDAL | VP VPE-891 |
| Grip | MERIDA Comp EC |
| Handlebar | MERIDA EXPERT CC, MAT aluminium, XXS/XS- 700WHB, S 720 WHB, 10 RHB |
| Stem | MERIDA COMP CC, MAT aluminium, 31.8 DSH, 7 ASD |
| Stem Size | 50mm |
| Headset | FSA NO.55R/57SC/57B |
| Hub Rear | Shimano QC300-HM, 135x9 WHR, 32 SPH, Centerlock |
| Rim | MERIDA COMP CC II, 25 IWR, MAT aluminium, tubeless ready |
| Saddle | MERIDA COMP SL, V-mount |
| SEAT CLAMP | MERIDA comp QR |
| SEAT POST | MERIDA COMP CC, MAT aluminium, 30.9 DSP, 0 SSB |
| SHIFTER FRONT | N/A |
| SHIFTER REAR | Shimano CUES U6000 |
| Tyre Front | Kenda Booster, 27.5"x2.4, wired |
| Tyre Rear | Kenda Booster, 27.5"x2.4, wired |
| Frame Material | Alloy |
| Fork Material | Alloy |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | CUES |
| Fork Brand | Suntour |
| Fork Travel | 101 - 120mm |
| Shock Travel | 101 - 120mm |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 10 |
| Ride Style | Trail |
