The Altitude Carbon is purpose-built to go fast and demolish steep trails. Fine tune your ride by opting for full 29'' or MX, using the built-in flip chip (sizes MD-XL) or adjust the RIDE-4™ with a single Allen key. Its total enduro capabilities can help you secure that “top step” and own those demanding group rides with confidence. The redesigned Altitude Carbon also features internal routing and the new PenaltyBox™ 2.0 downtube storage. With so much capability in your corner, it’s time to push limits, climb faster, and charge. Enduro lives at Altitude.
| frame | SMOOTHWALL™ Carbon | Penalty Box 2.0 Storage |Full Sealed Cartridge Bearings | Threaded BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel | SMOOTHWALL™ Carbon Rear Triangle |
| fork | Fox 38 Float EVOL GRIP Performance Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset |
| front travel | 170 |
| shock | Fox Float X Performance | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ |
| rear travel | 160 |
| headset | FSA Orbit NO.85 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race |
| stem | Rocky Mountain 35 AM | 0° Rise | All Sizes = 40mm |
| handlebar | Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp |
| rear derailleur | SHIMANO XT |
| brakes | Shimano XT Trail 4 Piston | Metal Pads |
| shifters | Shimano SLX |
| cranks & chainring | Race Face Aeffect Cinch | 32T | 24mm Spindle | SM = 165mm | MD - XL = 170mm |
| bottom bracket | Shimano Threaded BBMT501-B |
| cassette | Shimano SLX 10-51t 12spd |
| chain | Shimano M7100 |
| front hub | Novatec D791SB Sealed Boost 15mm |
| rear hub | DT Swiss 370 Boost 148mm | 18T Star-Ratchet |
| spokes | DT Swiss Competition 2.0/1.8/2.0 |
| rims | WTB ST i30 TOUGH TCS 2.0 | 32H | Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection |
| tires | Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready | Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready | Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection |
| seatpost | X Fusion Manic Composite 30.9mm | SM = 150mm | MD = 170mm | LG - XL = 200mm |
| saddle | WTB Solano Fusion Form 142 | Cromoly Rails |
| weight | This information isn't available yet. We will update the weight of this model as soon as possible. |
| Frame Material | Carbon |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | SLX |
| Fork Brand | Fox |
| Fork Travel | 141 - 170mm |
| Shock Travel | 141 - 170mm |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Enduro |
| FRAME | SMOOTHWALL™ Carbon | Penalty Box 2.0 Storage |Full Sealed Cartridge Bearings | Threaded BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel | SMOOTHWALL™ Carbon Rear Triangle |
| Fork | Fox 38 Float EVOL GRIP Performance Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset |
| FRONT TRAVEL | 170 |
| Shock | Fox Float X Performance | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ |
| REAR TRAVEL | 160 |
| Headset | FSA Orbit NO.85 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race |
| Stem | Rocky Mountain 35 AM | 0° Rise | All Sizes = 40mm |
| Handlebar | Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp |
| Rear Derailleur | SHIMANO XT |
| BRAKES | Shimano XT Trail 4 Piston | Metal Pads |
| Shifters | Shimano SLX |
| Cranks & Chainring | Race Face Aeffect Cinch | 32T | 24mm Spindle | SM = 165mm | MD - XL = 170mm |
| Bottom Bracket | Shimano Threaded BBMT501-B |
| Cassette | Shimano SLX 10-51t 12spd |
| Chain | Shimano M7100 |
| FRONT HUB | Novatec D791SB Sealed Boost 15mm |
| REAR HUB | DT Swiss 370 Boost 148mm | 18T Star-Ratchet |
| SPOKES | DT Swiss Competition 2.0/1.8/2.0 |
| RIMS | WTB ST i30 TOUGH TCS 2.0 | 32H | Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection |
| Tires | Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready | Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready | Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection |
| Seatpost | X Fusion Manic Composite 30.9mm | SM = 150mm | MD = 170mm | LG - XL = 200mm |
| Saddle | WTB Solano Fusion Form 142 | Cromoly Rails |
| Weight | This information isn't available yet. We will update the weight of this model as soon as possible. |
