Bikeradar's Trail Bike of the Year 2023, the ONE-FORTY 700 marries a high-value all-aluminium frame to high-performance equipment that won't let you down. Our radical trail geometry delivers the sort of climbing ability that would make a mountain goat proud while shaming enduro bikes with descending speed. Wide range, 12-speed SRAM drivetrain and four-piston brakes, high-performance Marzocchi suspension plus our long travel adjustable dropper post deliver unwavering performance.
The test and award-winning ONE-FORTY is the ultimate trail bike, made for the toughest trails in the world. It’s the pinnacle of modern trail riding, with a super-steep 80° seat angle, low front end and bottom bracket allow it to clear the most technical climbs, while longer reach figures across all sizes and a well-balanced 65° head angle mean it’s still more than capable of ripping any descent. With our AGILOMETER sizing system, riders can run a longer or shorter reach frame independently of their height, with suspension that becomes more progressive as you size up to better cope with heavier/harder riders. We’ve focused on weight reduction and rolling speed too, for improved efficiency. All bikes come with long travel dropper posts, WIRE PORT cable routing and a reliable threaded bottom bracket plus carbon frames have on-board tool storage and Fidlock magnetic bottle cages.
Features:
| frame | ONE-FORTY LITE III, 143 STR 29", MAT aluminium, 29x2.5" max. WHS, 148x12 AST, BSA BBR, |
| shock | Marzocchi Bomber Air, Air, platform, |
| fork | Marzocchi Z1, Air, 150 STR, Tapered, 44mm fork offset, 29x2.6" max. WHS, |
| brake front | Sram DB8 Stealth, 4 piston |
| brake rear | Sram DB8 Stealth, 4 piston |
| rotor front | Sram CenterLine, 200mm |
| rotor rear | Sram CenterLine, 200mm |
| chain | Sram Eagle 70 Transmission, Flattop |
| pedal | 0, |
| crank length | 170 mm for all sizes, |
| bb set | Sram DUB BSA 73 MTB Wide, |
| derailleur front | 0, |
| derailleur rear | Sram Eagle 90 Transmission, T-Type |
| cassette | Sram XS-1270 Eagle Transmission, 11-52t, 12sp |
| grip | MERIDA EXPERT TR, recycled material |
| handlebar | MERIDA EXPERT TR II, MAT aluminium, 780 WHB, XS/S 18 RHB, M/L/XL 30 RHB, |
| stem | MERIDA EXPERT eTRII, MAT aluminium, 35 DSH, 0 ASD |
| stem size | 40 mm, |
| headset | Acros ICR MERIDA EXTERNAL neck, Upper and lower IPS sealing |
| hub front | Shimano TC500-B, 110x15 WHF, 32 SPH, Centerlock |
| hub rear | Shimano TC600-HM-B, 148x12 WHR, 32 SPH, Centerlock |
| rim | Reynolds 329 Trail Comp, 32 IWR, MAT aluminium, Tubeless ready (tubeless tape installed), 29", |
| saddle | MERIDA COMP SL, 25% recycled material, V-mount, incl. MERIDA minitool |
| seat clamp | MERIDA EXPERT |
| shifter front | Sram Dropper Lever MMX, |
| shifter rear | Sram Eagle 90 Transmission MMX, |
| tyre front | Maxxis Minion DHF, 29x2.5", fold, TR, EXO+, 3C MaxxSpeed, |
| tyre rear | Maxxis Dissector, 29x2.4", fold, TR EXO+ MaxxTerra, |
| FRAME | ONE-FORTY LITE III, 143 STR 29", MAT aluminium, 29x2.5" max. WHS, 148x12 AST, BSA BBR, |
| Shock | Marzocchi Bomber Air, Air, platform, |
| Fork | Marzocchi Z1, Air, 150 STR, Tapered, 44mm fork offset, 29x2.6" max. WHS, |
| Brake Front | Sram DB8 Stealth, 4 piston |
| Brake Rear | Sram DB8 Stealth, 4 piston |
| ROTOR FRONT | Sram CenterLine, 200mm |
| ROTOR REAR | Sram CenterLine, 200mm |
| Chain | Sram Eagle 70 Transmission, Flattop |
| PEDAL | 0, |
| Crank Length | 170 mm for all sizes, |
| BB Set | Sram DUB BSA 73 MTB Wide, |
| DERAILLEUR FRONT | 0, |
| DERAILLEUR REAR | Sram Eagle 90 Transmission, T-Type |
| Cassette | Sram XS-1270 Eagle Transmission, 11-52t, 12sp |
| Grip | MERIDA EXPERT TR, recycled material |
| Handlebar | MERIDA EXPERT TR II, MAT aluminium, 780 WHB, XS/S 18 RHB, M/L/XL 30 RHB, |
| Stem | MERIDA EXPERT eTRII, MAT aluminium, 35 DSH, 0 ASD |
| Stem Size | 40 mm, |
| Headset | Acros ICR MERIDA EXTERNAL neck, Upper and lower IPS sealing |
| Hub Front | Shimano TC500-B, 110x15 WHF, 32 SPH, Centerlock |
| Hub Rear | Shimano TC600-HM-B, 148x12 WHR, 32 SPH, Centerlock |
| Rim | Reynolds 329 Trail Comp, 32 IWR, MAT aluminium, Tubeless ready (tubeless tape installed), 29", |
| Saddle | MERIDA COMP SL, 25% recycled material, V-mount, incl. MERIDA minitool |
| SEAT CLAMP | MERIDA EXPERT |
| SHIFTER FRONT | Sram Dropper Lever MMX, |
| SHIFTER REAR | Sram Eagle 90 Transmission MMX, |
| Tyre Front | Maxxis Minion DHF, 29x2.5", fold, TR, EXO+, 3C MaxxSpeed, |
| Tyre Rear | Maxxis Dissector, 29x2.4", fold, TR EXO+ MaxxTerra, |
| Frame Material | Alloy |
| Fork Material | Alloy |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Sram |
| Groupset Model | Eagle 90 |
| Fork Brand | Marzocchi |
| Fork Travel | 141 - 170mm |
| Shock Travel | 121 - 140mm |
| Shifting Type | Mechanical |
| Pedals Included | No |
| Drivetrain Gearing | 1 x 12 |
| Ride Style | Enduro |
