The entry to the world of MERIDA mountain bike hardtails. Our latest high-quality TFS frame takes everything we know about aluminium frame manufacturing, with updated geometry that delivers more on-trail performance without losing all-around versatility. The SR Suntour 100 mm suspension fork is paired with more agile 27.5" wheels smooth the bumps and the Shimano disc brakes and 2x7-speed drivetrain deliver reliable and confident performance.
When it comes to the demanding world of cross-country mountain biking, the classic hardtail remains one of the purest tools for the job. Our 29er wheel equipped BIG.NINE range comes with the choice of carbon or two different aluminium frames to deliver a ride for all budgets. The latest CF carbon and LITE aluminium framed BIG.NINE offer truly modern geometry with increased standover clearance and handling stability to better deal with the tough race tracks of today. They also have downcountry ready TR options that boost fork travel and add in aggressive tyres and dropper posts. For riders starting out, the updated BIG.NINE TFS offers more relaxed geometry and builds that deliver great value and versatility on or off the trail, with BIG.SEVEN TFS models using 27.5" wheels to deliver size for shorter riders. Our classic XC hardtails are the backbone of our range and showcase the enormous wealth of experience and knowledge we have gained in over half a century of bike production and manufacturing. The BIG.NINE range represents the symbiosis between modern frame technology, attention to detail and craftsmanship that 'Made in Taiwan' stands for.
| frame | BIG.SEVEN TFS V |
| fork | SR Suntour XCE28 |
| rim | MERIDA COMP CC |
| hubs | Shimano TX505 |
| front tyre | Kenda K1080 |
| rear tyre | Kenda K1080 |
| crank | Prowheel TM-CY10 |
| bottom bracket | FSA TH-7420ST |
| cassette | Shimano CS-HG210-7 |
| chain | KMC Z7 |
| shifters | Shimano Altus EF-500-2L / Shimano Altus EF-500-7R |
| front derailleur | Shimano Altus FD-M315 |
| rear derailleur | Shimano Tourney TY300 |
| brakes | Shimano BR-M375 |
| rotors | Shimano RT10 |
| headset | FSA NO.55R/57SC/57B |
| stem | MERIDA COMP CC |
| stem size | 50mm |
| handlebar | MERIDA CC |
| grip | MERIDA EC |
| seat post | MERIDA CC |
| saddle | Merida Sport |
| seat clamp | MERIDA comp QR |
| pedal | VP VPE-891 |
| frame size | XS, S |
| FRAME | BIG.SEVEN TFS V |
| Fork | SR Suntour XCE28 |
| Rim | MERIDA COMP CC |
| HUBS | Shimano TX505 |
| FRONT TYRE | Kenda K1080 |
| REAR TYRE | Kenda K1080 |
| CRANK | Prowheel TM-CY10 |
| Bottom Bracket | FSA TH-7420ST |
| Cassette | Shimano CS-HG210-7 |
| Chain | KMC Z7 |
| Shifters | Shimano Altus EF-500-2L / Shimano Altus EF-500-7R |
| Front Derailleur | Shimano Altus FD-M315 |
| Rear Derailleur | Shimano Tourney TY300 |
| BRAKES | Shimano BR-M375 |
| Rotors | Shimano RT10 |
| Headset | FSA NO.55R/57SC/57B |
| Stem | MERIDA COMP CC |
| Stem Size | 50mm |
| Handlebar | MERIDA CC |
| Grip | MERIDA EC |
| SEAT POST | MERIDA CC |
| Saddle | Merida Sport |
| SEAT CLAMP | MERIDA comp QR |
| PEDAL | VP VPE-891 |
| Frame Material | Alloy |
| Fork Material | Alloy |
| Brake Type | Mechanical Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | Altus |
| Fork Brand | Suntour |
| Fork Travel | 0 - 100mm |
| Shock Travel | 0 - 100mm |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 1 x 7 |
| Ride Style | Trail |
| Frame Size | XS, S |
