The mountain bike experience starts here. With a redesigned frame that’s now lighter and more durable, along with a smooth-riding suspension fork, thru-axle hubs*, and a 1x drivetrain*, this aluminum hardtail is everything an aspiring MTB rider needs to evolve and advance. *on select models
Modern MTB Design
Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models
Off-Road Control
New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.
Light and Durable
All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.
****NOTE: This bike is available for purchase online, but must
be picked up from an approved store.| frame | ALUXX-Grade aluminium, disc |
| fork | SXC32-3 RL, coil spring, Boost 15x110 XS - 80mm travel (27.5) S - 80mm travel (27.5) / 100mm travel (29) M - 100mm travel (29), L - 100mm travel (29) XL - 100mm travel (29) |
| shock | N/A |
| handlebar | Giant Connect Trail, 31.8mm |
| grips | Giant Sole-O |
| stem | Giant Sport, 7-degree XS - 40mm (27.5) S - 50mm (27.5) / 50mm (29) M - 60mm (29) L - 70mm (29) XL - 80mm (29) |
| seatpost | Giant Contact Switch Core dropper, remote XS - 100mm travel / 30.9 x 350mm S - 100mm travel / 30.9 x 350mm M - 120mm travel / 30.9 x 400mm L - 120mm travel / 30.9 x 400mm XL - 120mm travel / 30.9 x 400mm |
| saddle | Giant ErgoContact Trail |
| pedals | MTB caged |
| shifters | Shimano CUES, SL-6000, 1x10 |
| front derailleur | N/A |
| rear derailleur | Shimano CUES, U6000, Shadow+ |
| brakes | Tektro HDM275, hydraulic, Tektro rotors [F]180mm, [R]160mm |
| brake levers | Tektro HDM275 |
| cassette | ProWheel Charm, 32t (27.5), 30t (29) XS - 165mm (27.5) S - 165mm (27.5) / 170mm (29) M - 170mm (29) L - 170mm (29) |
| chain | KMC X11 |
| crankset | ProWheel Charm, 30t S - 170mm M - 170mm L - 170mm XL - 175mm |
| bottom bracket | Cartridge |
| rims | Alloy, sealed |
| hubs | Alloy, sealed |
| spokes | stainless, 14G |
| tires | Maxxis Rekon Race 27.5" or 29x2.4", wire bead |
| extras | 2.4" max tyre size, 32t max chainring size |
| FRAME | ALUXX-Grade aluminium, disc |
| Fork | SXC32-3 RL, coil spring, Boost 15x110 XS - 80mm travel (27.5) S - 80mm travel (27.5) / 100mm travel (29) M - 100mm travel (29), L - 100mm travel (29) XL - 100mm travel (29) |
| Shock | N/A |
| Handlebar | Giant Connect Trail, 31.8mm |
| GRIPS | Giant Sole-O |
| Stem | Giant Sport, 7-degree XS - 40mm (27.5) S - 50mm (27.5) / 50mm (29) M - 60mm (29) L - 70mm (29) XL - 80mm (29) |
| Seatpost | Giant Contact Switch Core dropper, remote XS - 100mm travel / 30.9 x 350mm S - 100mm travel / 30.9 x 350mm M - 120mm travel / 30.9 x 400mm L - 120mm travel / 30.9 x 400mm XL - 120mm travel / 30.9 x 400mm |
| Saddle | Giant ErgoContact Trail |
| PEDALS | MTB caged |
| Shifters | Shimano CUES, SL-6000, 1x10 |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano CUES, U6000, Shadow+ |
| BRAKES | Tektro HDM275, hydraulic, Tektro rotors [F]180mm, [R]160mm |
| Brake Levers | Tektro HDM275 |
| Cassette | ProWheel Charm, 32t (27.5), 30t (29) XS - 165mm (27.5) S - 165mm (27.5) / 170mm (29) M - 170mm (29) L - 170mm (29) |
| Chain | KMC X11 |
| Crankset | ProWheel Charm, 30t S - 170mm M - 170mm L - 170mm XL - 175mm |
| Bottom Bracket | Cartridge |
| RIMS | Alloy, sealed |
| HUBS | Alloy, sealed |
| SPOKES | stainless, 14G |
| Tires | Maxxis Rekon Race 27.5" or 29x2.4", wire bead |
| EXTRAS | 2.4" max tyre size, 32t max chainring size |
| Frame Material | Alloy |
| Fork Material | Suspension |
| Brake Type | Hydraulic Disc Brake |
| Groupset Brand | Shimano |
| Groupset Model | CUES |
| Fork Brand | Giant |
| Fork Travel | 0 - 100mm |
| Shifting Type | Mechanical |
| Pedals Included | Yes |
| Drivetrain Gearing | 1 x 10 |
| Ride Style | Sport |
